To facilitate global customers in gaining an in-depth understanding of product technical details and selection methods,this page provides free downloads of comprehensive product resources, covering three core categories: First, Product Datasheets, which include international standard parameters, performance indicators,and application scenarios for all products such as energy storage systems,charging piles,and recloser controllers.Second,Operation Manuals,offering multilingual guides for product installation,commissioning,and daily maintenance. Third, Technical Whitepapers, focusing on cutting-edge industry technologies, core product advantages, and case studies of typical applications. All materials comply with international industry standards and are available for download in PDF format.For customized technical documents,please contact customer service.
Restricted.
Capacitor bank controller used manual
Operating Instruction
English
PDF
This document describes capacitor‑switch controller. It complies with IEC 60255‑1:2022 general requirements for measuring relays and IEC 60255‑27:2023 product‑safety (including insulation) requirements. It meets mechanical environmental tests IEC 60255‑21‑1 and full‑set EMC standard IEC 60255‑26:2023. Environmental performance follows IEC 60068‑2 and IEC 60068‑2‑78. Compatible with vacuum, oil, gas circuit‑breakers and permanent‑magnet actuators. Configurable trip/close pulse width and dead‑time
Restricted.
RWK-35 Automatic Recloser controller used manual
Operating Instruction
English
PDF
This document describes pole‑mounted recloser controller complying with IEC 60255‑1:2022, IEC 60255‑26:2023, IEC 60255‑27:2023, with mechanical tests IEC 60255‑21‑1/2/3 and climatic tests IEC 60068‑2‑1/2, IEC 60068‑2‑78. It integrates phase overcurrent, earth‑fault, sensitive earth‑fault, negative‑sequence, frequency, synchronism‑check, cold‑load pickup and SOTF protection. Time‑scheduled setting‑group auto‑switching and upstream‑downstream sequence‑coordination logic are available. Local LCD‑ke
Restricted.
General Protection Device
Operating Instruction
English
PDF
This document describes general‑purpose feeder protection & control device complying with IEC 60255‑1:2022, IEC 60255‑26:2023, IEC 60255‑27:2023, with mechanical tests IEC 60255‑21‑1and climatic tests IEC 60068‑2‑1, IEC 60068‑2‑78. It integrates three‑stage phase overcurrent and sensitive earth‑fault protection with directional earth‑fault, cold‑load pickup, reclose‑acceleration, manual close‑acceleration, over‑voltage & under‑voltage functions. The maximum primary‑side setting value for
Restricted.
RWK-LC Smart Switch Controller used manual
Operating Instruction
English
PDF
Smart Switch Controller is medium voltage overhead line grid monitoring unit, it can be equipped with RCW(RVB) type vacuum circuit breaker for achieve of automatic monitoring, fault analysis and event records.ROCKWILL RWK-LC Smart Switch Controller is a high-reliability field intelligent control terminal for distribution automation equipment. It adopts industrial-grade high-speed CPU chip and high-precision signal sampling circuit, supporting real-time collection of line voltage, current and swi
